Two-sided non-screw rack shelving systems
The company "Everything for shops and warehouses" offers robust galvanized shelving systems for heavy loads. These shelves are suitable for a wide range of applications: warehouses, archives, offices, workrooms, car service shops, shops, garages, etc.
Overall specification
| Model number | Shelves |
1 shelf load capacity |
Height |
Width |
Depth |
| VVN NRS5 | 5 | 90 kg | 2000 mm | 1000 mm | 600 mm (2x300 mm) |
| VVN NRS6 | 5 | 90 kg | 2200 mm | 1000 mm | 600 mm (2x300 mm) |
| VVN NRS7 | 5 | 90 kg | 2000 mm | 1000 mm | 600 mm (2x300 mm) |
| VVN NRS8 | 5 | 90 kg | 2200 mm | 1000 mm | 600 mm (2x300 mm) |
Technical specification of two sided non-screwless shelving systems:
Possibility to add additional sections;
The rack section is based on 4 supports;
The rear supports are connected to the links (crosswise);
The supports are with plastic sleeves - pallets;
Shelf adjustment step - 25 mm;
Includes a one-piece steel slab that serves as a side edge;
Additional fasteners - additional fastenings are required on the floor if specified in the TS, but the bolts are not included in the offer and price.
